额定载荷Rated Load
|
7.5t、10t 、15t、 20t
|
|
额定输出Rated Output
|
2.0000±0.001MV/V
|
|
综合误差Total Error
|
±0.1%F.S
|
|
蠕变Creep(30minutes)
|
±0.02%F.S
|
|
推荐工作电压Recommended Excitation Voltage
|
5V～12V(AC or DC)
|
|
最大工作电压Maximum Excitation Voltage
|
15V(AC or DC)
|
|
零点平衡Zero Balance
|
±1%F.S
|
|
输入阻抗Input Impedance
|
380±5Ω
|
|
输出阻抗Output Impedance
|
350±2Ω
|
|
绝缘阻抗Insulation Impedance
|
≥5000MΩ
|
|
安全过载率Safe Overload
|
150%F.S
|
|
极限过载率Ultimate Overload
|
200%F.S
|
|
工作温度范围Operating Temperature Range
|
(-30～+70)℃
|
|
温度补偿范围Compensated Temperature Range
|
(-20～+60)℃
|
|
输出温度影响Temperature Effect On Load
|
±0.02%F.S/10℃
|
|
零点温度影响Temperature Effect On Zero
|
±0.02%F.S/10℃
|
|
材质Construction
|
合金钢Alloy Steel
|
|
防护等级Protection Class
|
IP68&IP67
|
|
引用标准Citation
|
GB/T7551-2008/OIML R60
|
|
接线方式Mode of Connection
|
输入+:红 Input+:Red
输入-:黑 Input-:Black
输出+:绿 Output+:Green
输出-:白 Output-:White
|
\\
